CS5106LSWR24

Part No :: CS5106LSWR24

Manufacturer: Sanyo Semiconductor/ON Semiconductor

VIGOR # :: 4895545

Description: IC REG CTRLR FWRD CONV 24SSOP

Catalog: PMIC - Voltage Regulators - DC DC Switching Controllers

DataSheet: CS5106LSWR24 PDF

Country of origin: -

Date code: -

CS5106LSWR24 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)
Part Status:	Obsolete
Output Type:	Transistor Driver
Function:	Step-Up/Step-Down
Output Configuration:	Positive, Isolation Capable
Topology:	Forward Converter
Number of Outputs:	1
Output Phases:	1
Voltage - Supply (Vcc/Vdd):	9V ~ 16V
Frequency - Switching:	512kHz
Duty Cycle (Max):	60%
Synchronous Rectifier:	Yes
Clock Sync:	Yes
Serial Interfaces:	-
Control Features:	Current Limit, Enable, Frequency Control, Ramp
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Package / Case:	24-SSOP (0.209", 5.30mm Width)
Supplier Device Package:	24-SSOP
