UC2843BD

Part No :: UC2843BD

Manufacturer: Sanyo Semiconductor/ON Semiconductor

VIGOR # :: 4895865

Description: IC REG CTRLR FLYBACK 14SOIC

Catalog: PMIC - Voltage Regulators - DC DC Switching Controllers

DataSheet: UC2843BD PDF

Country of origin: -

Date code: -

UC2843BD Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Output Type:	Transistor Driver
Function:	Step-Up, Step-Up/Step-Down
Output Configuration:	Positive, Isolation Capable
Topology:	Boost, Flyback
Number of Outputs:	1
Output Phases:	1
Voltage - Supply (Vcc/Vdd):	7.6V ~ 30V
Frequency - Switching:	Up to 500kHz
Duty Cycle (Max):	96%
Synchronous Rectifier:	No
Clock Sync:	No
Serial Interfaces:	-
Control Features:	Frequency Control
Operating Temperature:	-25°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Package / Case:	14-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	14-SOIC
