MAX8540EEE+

Part No :: MAX8540EEE+

Manufacturer: Maxim Integrated

VIGOR # :: 4896749

Description: IC REG CTRLR MULT TOP 16QSOP

Catalog: PMIC - Voltage Regulators - DC DC Switching Controllers

DataSheet: MAX8540EEE+ PDF

Country of origin: -

Date code: -

MAX8540EEE+ Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Output Type:	Transistor Driver
Function:	Step-Up/Step-Down
Output Configuration:	Positive, Isolation Capable
Topology:	Flyback, Forward Converter
Number of Outputs:	1
Output Phases:	1
Voltage - Supply (Vcc/Vdd):	7.6V ~ 18V
Frequency - Switching:	200kHz ~ 1MHz
Duty Cycle (Max):	80%
Synchronous Rectifier:	No
Clock Sync:	Yes
Serial Interfaces:	-
Control Features:	Current Limit, Enable, Frequency Control, On Time Control, Ramp, Soft Start
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Package / Case:	16-SSOP (0.154", 3.90mm Width)
Supplier Device Package:	16-QSOP
