AP1509-SG-13

Part No :: AP1509-SG-13

Manufacturer: Zetex Semiconductors (Diodes Inc.)

VIGOR # :: 3894874

Description: IC REG BUCK ADJUSTABLE 2A 8SOP

Catalog: PMIC - Voltage Regulators - DC DC Switching Regulators

DataSheet: AP1509-SG-13 PDF

Country of origin: -

Date code: -

AP1509-SG-13 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Function:	Step-Down
Output Configuration:	Positive
Topology:	Buck
Output Type:	Adjustable
Number of Outputs:	1
Voltage - Input (Min):	4.5V
Voltage - Input (Max):	22V
Voltage - Output (Min/Fixed):	1.23V
Voltage - Output (Max):	18V
Current - Output:	2A
Frequency - Switching:	150kHz
Synchronous Rectifier:	No
Operating Temperature:	-20°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOP

Alternative Products

Part Number	Manufacturer & Description	Compare
AP1509-33SG-13 Match 100%	Zetex Semiconductors (Diodes Inc.) IC REG BUCK 3.3V 2A 8SOP	AP1509-SG-13 vs AP1509-33SG-13
AP1509-50SG-13 Match 100%	Zetex Semiconductors (Diodes Inc.) IC REG BUCK 5V 2A 8SOP	AP1509-SG-13 vs AP1509-50SG-13
RT8284GS Match 100%	Richtek IC REG BUCK ADJUSTABLE 2A 8SOP	AP1509-SG-13 vs RT8284GS
TS3552CS RLG Match 100%	TSC (Taiwan Semiconductor) IC REG BUCK ADJUSTABLE 2A 8SOP	AP1509-SG-13 vs TS3552CS RLG
RT8284NGS Match 100%	Richtek IC REG BUCK ADJUSTABLE 2A 8SOP	AP1509-SG-13 vs RT8284NGS
AP1513SG-13 Match 100%	Zetex Semiconductors (Diodes Inc.) IC REG BUCK ADJUSTABLE 2A 8SOP	AP1509-SG-13 vs AP1513SG-13
