NCV47701PDAJR2G

Part No :: NCV47701PDAJR2G

Manufacturer: Sanyo Semiconductor/ON Semiconductor

Description: IC REG LIN POS ADJ 350MA 8SOIC

Catalog: PMIC - Voltage Regulators - Linear

DataSheet: NCV47701PDAJR2G PDF

Availability: 161 pieces

Current price of NCV47701PDAJR2G is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

NCV47701PDAJR2G Specifications

Type	Description
Series:	Automotive, AEC-Q100
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Output Configuration:	Positive
Output Type:	Adjustable
Number of Regulators:	1
Voltage - Input (Max):	40V
Voltage - Output (Min/Fixed):	5V
Voltage - Output (Max):	20V
Voltage Dropout (Max):	0.5V @ 150mA
Current - Output:	350mA
Current - Quiescent (Iq):	230 µA
Current - Supply (Max):	50 mA
PSRR:	70dB (100Hz)
Control Features:	Enable
Protection Features:	Over Current, Over Temperature, Reverse Polarity
Operating Temperature:	-40°C ~ 150°C
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOIC
