LP38691SD-5.0/NOPB

Part No :: LP38691SD-5.0/NOPB

Manufacturer: Texas Instruments

Description: IC REG LINEAR 5V 500MA 6WSON

Catalog: PMIC - Voltage Regulators - Linear

DataSheet: LP38691SD-5.0/NOPB PDF

Availability: 2187 pieces

Current price of LP38691SD-5.0/NOPB is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

LP38691SD-5.0/NOPB Specifications

Type	Description
Series:	Automotive, AEC-Q100
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Output Configuration:	Positive
Output Type:	Fixed
Number of Regulators:	1
Voltage - Input (Max):	10V
Voltage - Output (Min/Fixed):	5V
Voltage - Output (Max):	-
Voltage Dropout (Max):	0.45V @ 500mA
Current - Output:	500mA
Current - Quiescent (Iq):	55 µA
Current - Supply (Max):	100 µA
PSRR:	55dB (120Hz)
Control Features:	-
Protection Features:	Over Temperature
Operating Temperature:	-40°C ~ 125°C
Mounting Type:	Surface Mount
Package / Case:	6-WDFN Exposed Pad
Supplier Device Package:	6-WSON (3x3)
