L7815CV-DG

Part No :: L7815CV-DG

Manufacturer: STMicroelectronics

Description: IC REG LINEAR 15V 1.5A TO220

Catalog: PMIC - Voltage Regulators - Linear

DataSheet: L7815CV-DG PDF

Availability: 1969 pieces

Current price of L7815CV-DG is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

L7815CV-DG Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Output Configuration:	Positive
Output Type:	Fixed
Number of Regulators:	1
Voltage - Input (Max):	35V
Voltage - Output (Min/Fixed):	15V
Voltage - Output (Max):	-
Voltage Dropout (Max):	2V @ 1A (Typ)
Current - Output:	1.5A
Current - Quiescent (Iq):	8 mA
Current - Supply (Max):	-
PSRR:	54dB (120Hz)
Control Features:	-
Protection Features:	Over Temperature, Short Circuit
Operating Temperature:	0°C ~ 125°C
Mounting Type:	Through Hole
Package / Case:	TO-220-3
Supplier Device Package:	TO-220
