LM7809ACT

Product image
Product thumb
Part No :

LM7809ACT

Manufacturer
VIGOR
VIGOR # :

3759486

Description
IC REG LINEAR 9V 1A TO220-3
Catalog
PMIC - Voltage Regulators - Linear
DataSheet
LM7809ACT PDF
Country of origin
-
Date code
-
ads
LM7809ACT Specifications
Type Description
Series:-
Package:Bulk
Part Status:Obsolete
Output Configuration:Positive
Output Type:Fixed
Number of Regulators:1
Voltage - Input (Max):35V
Voltage - Output (Min/Fixed):9V
Voltage - Output (Max):-
Voltage Dropout (Max):2V @ 1A (Typ)
Current - Output:1A
Current - Quiescent (Iq):8 mA
Current - Supply (Max):-
PSRR:71dB (120Hz)
Control Features:-
Protection Features:Over Temperature, Short Circuit
Operating Temperature:0°C ~ 125°C
Mounting Type:Through Hole
Package / Case:TO-220-3
Supplier Device Package:TO-220-3
