IL 3522E

Product image
Product thumb
Part No :

IL 3522E

Manufacturer
NVE Corporation
VIGOR # :

4079102

Description
DGT ISO 2.5KV RS422/RS485 16SOIC
Catalog
Digital Isolators
DataSheet
IL 3522E PDF
Country of origin
-
Date code
-
ads
IL 3522E Specifications
Type Description
Series:IsoLoop®
Package:Tube
Part Status:Active
Technology:GMR (Giant Magnetoresistive)
Type:RS422, RS485
Isolated Power:No
Number of Channels:3
Inputs - Side 1/Side 2:2/1
Channel Type:Unidirectional
Voltage - Isolation:2500Vrms
Common Mode Transient Immunity (Min):30kV/µs
Data Rate:40Mbps
Propagation Delay tpLH / tpHL (Max):35ns, 35ns
Pulse Width Distortion (Max):-
Rise / Fall Time (Typ):-
Voltage - Supply:3V ~ 5.5V, 4.5V ~ 5.5V
Operating Temperature:-40°C ~ 85°C
Mounting Type:Surface Mount
Package / Case:16-SOIC (0.295", 7.50mm Width)
Supplier Device Package:16-SOIC
  • Please confirm the specifications of the products when ordering.
  • MOQ means the minimum order quantity required to purchase each parts.
  • If you have special order instructions,please note it on the ordering pages.
  • The Pre-Shipment Inspection (PSI) will be applied.
  • You can email us to change the order details before shipment.
  • Orders cannot be canceled after shipping the packages.
  • TT in advance (bank transfer), Credit Card, PayPal can be chosen.
  • Cash transfer only. (Transfer with checks and bills are not accepted.)
  • Customer is responsible for paying all possible charges,including sales tax, VAT and customs charges,etc.
  • If you need the detailed invoice or tax ID,please email us.
  • FedEx, DHL, and UPS can be selected.
  • You can select whether to charge shipping fee by your shipping account or to charge by our side.
  • Please confirm with the logistics company in advance if you are in a remote area. (It may cost extra fees (35-50 USD) for delivery at those areas.)
  • The shopping cart will automatically calculate the shipping cost.
  • Delivery time: At the same day (Order deadline is 2pm, HK Time).
  • Delivery date: usually 2 to 7 working days.
  • It is unable to appoint a date of delivery.
  • Tracking number will be sent once your order has been shipped. (It may take up to 24 hours before carriers display the info.)
In Stock: 15750
Shipped from
HK warehouse
Expected Shipping Date
Oct 10 - Oct 14 2026
Pricing(USD)
Quantity Unit Price Ext. Price
1 $6.2582 $6.26

Current price of IL 3522E is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
