MAX14949EWE+

Part No :: MAX14949EWE+

Manufacturer: Maxim Integrated

VIGOR # :: 4079146

Description: DGTL ISO 5KV RS422/RS485 16SOIC

Catalog: Digital Isolators

DataSheet: MAX14949EWE+ PDF

Country of origin: -

Date code: -

MAX14949EWE+ Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Technology:	Capacitive Coupling
Type:	RS422, RS485
Isolated Power:	No
Number of Channels:	3
Inputs - Side 1/Side 2:	2/1
Channel Type:	Unidirectional
Voltage - Isolation:	5000Vrms
Common Mode Transient Immunity (Min):	35kV/µs (Typ)
Data Rate:	500kbps
Propagation Delay tpLH / tpHL (Max):	-
Pulse Width Distortion (Max):	-
Rise / Fall Time (Typ):	-
Voltage - Supply:	3V ~ 5.5V, 4.5V ~ 5.5V
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Surface Mount
Package / Case:	16-SOIC (0.295", 7.50mm Width)
Supplier Device Package:	16-SOIC
