IL 614

Part No :: IL 614

Manufacturer: NVE Corporation

VIGOR # :: 4978222

Description: DGTL ISO 2500VRMS 3CH GP 16SOIC

Catalog: Digital Isolators

DataSheet: IL 614 PDF

Country of origin: -

Date code: -

IL 614 Specifications

Type	Description
Series:	IsoLoop®
Package:	Tube
Part Status:	Obsolete
Technology:	GMR (Giant Magnetoresistive)
Type:	General Purpose
Isolated Power:	No
Number of Channels:	3
Inputs - Side 1/Side 2:	2/1
Channel Type:	Unidirectional
Voltage - Isolation:	2500Vrms
Common Mode Transient Immunity (Min):	15kV/µs
Data Rate:	40Mbps
Propagation Delay tpLH / tpHL (Max):	25ns, 25ns
Pulse Width Distortion (Max):	10ns
Rise / Fall Time (Typ):	2ns, 2ns
Voltage - Supply:	3V ~ 5.5V
Operating Temperature:	-55°C ~ 125°C
Mounting Type:	Surface Mount
Package / Case:	16-SOIC (0.295", 7.50mm Width)
Supplier Device Package:	16-SOIC
