UCC5320SCDWVR

Product image
Product thumb
Part No :

UCC5320SCDWVR

Manufacturer
Texas Instruments
VIGOR # :

4088573

Description
2A /2A 5KVRMS ISOGATE DR-SPLIT O
Catalog
Isolators - Gate Drivers
DataSheet
UCC5320SCDWVR PDF
Country of origin
-
Date code
-
ads
UCC5320SCDWVR Specifications
Type Description
Series:-
Package:Tape & Reel (TR)Cut Tape (CT)
Part Status:Active
Technology:Capacitive Coupling
Number of Channels:1
Voltage - Isolation:3000Vrms
Common Mode Transient Immunity (Min):100kV/µs
Propagation Delay tpLH / tpHL (Max):75ns, 75ns
Pulse Width Distortion (Max):20ns
Rise / Fall Time (Typ):12ns, 10ns
Current - Output High, Low:2.4A, 2.2A
Current - Peak Output:4.3A
Voltage - Forward (Vf) (Typ):-
Current - DC Forward (If) (Max):-
Voltage - Output Supply:13.2V ~ 33V
Operating Temperature:-40°C ~ 125°C
Mounting Type:Surface Mount
Package / Case:8-SOIC (0.295", 7.50mm Width)
Supplier Device Package:8-SOIC
Approval Agency:CQC, UR, VDE
