HCPL-2211

Part No :: HCPL-2211

Manufacturer: Broadcom

VIGOR # :: 4081147

Description: OPTOISO 3.75KV PUSH PULL 8DIP

Catalog: Optoisolators - Logic Output

DataSheet: HCPL-2211 PDF

Country of origin: -

Date code: -

HCPL-2211 Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Number of Channels:	1
Inputs - Side 1/Side 2:	1/0
Voltage - Isolation:	3750Vrms
Common Mode Transient Immunity (Min):	5kV/µs, 10kV/µs
Input Type:	DC
Output Type:	Push-Pull, Totem Pole
Current - Output / Channel:	25 mA
Data Rate:	5MBd
Propagation Delay tpLH / tpHL (Max):	300ns, 300ns
Rise / Fall Time (Typ):	30ns, 7ns
Voltage - Forward (Vf) (Typ):	1.5V
Current - DC Forward (If) (Max):	10mA
Voltage - Supply:	4.5V ~ 20V
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Through Hole
Package / Case:	8-DIP (0.300", 7.62mm)
Supplier Device Package:	8-DIP
