HCPL-2601-320E

Product image
Product thumb
Part No :

HCPL-2601-320E

Manufacturer
Broadcom
VIGOR # :

4081655

Description
OPTOISO 5KV OPEN COLL 8DIP GW
Catalog
Optoisolators - Logic Output
DataSheet
HCPL-2601-320E PDF
Country of origin
-
Date code
-
ads
HCPL-2601-320E Specifications
Type Description
Series:-
Package:Tube
Part Status:Active
Number of Channels:1
Inputs - Side 1/Side 2:1/0
Voltage - Isolation:5000Vrms
Common Mode Transient Immunity (Min):10kV/µs
Input Type:DC
Output Type:Open Collector, Schottky Clamped
Current - Output / Channel:50 mA
Data Rate:10MBd
Propagation Delay tpLH / tpHL (Max):100ns, 100ns
Rise / Fall Time (Typ):24ns, 10ns
Voltage - Forward (Vf) (Typ):1.5V
Current - DC Forward (If) (Max):20mA
Voltage - Supply:4.5V ~ 5.5V
Operating Temperature:-40°C ~ 85°C
Mounting Type:Surface Mount
Package / Case:8-SMD, Gull Wing
Supplier Device Package:8-DIP Gull Wing
