HCPL-2300-560E

Product image
Product thumb
Part No :

HCPL-2300-560E

Manufacturer
Broadcom
VIGOR # :

4081809

Description
OPTOISO 3.75KV OPEN COLL 8DIP GW
Catalog
Optoisolators - Logic Output
DataSheet
HCPL-2300-560E PDF
Country of origin
-
Date code
-
ads
HCPL-2300-560E Specifications
Type Description
Series:-
Package:Tape & Reel (TR)
Part Status:Active
Number of Channels:1
Inputs - Side 1/Side 2:1/0
Voltage - Isolation:3750Vrms
Common Mode Transient Immunity (Min):100V/µs
Input Type:DC
Output Type:Open Collector, Schottky Clamped
Current - Output / Channel:25 mA
Data Rate:5MBd
Propagation Delay tpLH / tpHL (Max):160ns, 200ns
Rise / Fall Time (Typ):40ns, 20ns
Voltage - Forward (Vf) (Typ):1.3V
Current - DC Forward (If) (Max):5mA (Typ)
Voltage - Supply:4.75V ~ 5.25V
Operating Temperature:-40°C ~ 85°C
Mounting Type:Surface Mount
Package / Case:8-SMD, Gull Wing
Supplier Device Package:8-DIP Gull Wing
