HCPL-7720-320

Part No :: HCPL-7720-320

Manufacturer: Broadcom

VIGOR # :: 4978704

Description: OPTOISO 5KV PUSH PULL 8DIP GW

Catalog: Optoisolators - Logic Output

DataSheet: HCPL-7720-320 PDF

Country of origin: -

Date code: -

HCPL-7720-320 Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Discontinued at Digi-Key
Number of Channels:	1
Inputs - Side 1/Side 2:	1/0
Voltage - Isolation:	5000Vrms
Common Mode Transient Immunity (Min):	10kV/µs
Input Type:	Logic
Output Type:	Push-Pull, Totem Pole
Current - Output / Channel:	10 mA
Data Rate:	25MBd
Propagation Delay tpLH / tpHL (Max):	40ns, 40ns
Rise / Fall Time (Typ):	9ns, 8ns
Voltage - Forward (Vf) (Typ):	-
Current - DC Forward (If) (Max):	-
Voltage - Supply:	4.5V ~ 5.5V
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Surface Mount
Package / Case:	8-SMD, Gull Wing
Supplier Device Package:	8-DIP Gull Wing
