ACPL-K376-560E

Part No :: ACPL-K376-560E

Manufacturer: Broadcom

Description: OPTOISO 5KV DARL 8-SO STRETCHED

Catalog: Optoisolators - Transistor, Photovoltaic Output

DataSheet: ACPL-K376-560E PDF

Availability: 472 pieces

Unit Price: ~~$6.74000~~

Current price of ACPL-K376-560E is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

ACPL-K376-560E Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Number of Channels:	1
Voltage - Isolation:	5000Vrms
Current Transfer Ratio (Min):	-
Current Transfer Ratio (Max):	-
Turn On / Turn Off Time (Typ):	6.3µs, 6.4µs
Rise / Fall Time (Typ):	24µs, 0.4µs
Input Type:	AC, DC
Output Type:	Darlington
Voltage - Output (Max):	20V
Current - Output / Channel:	30mA
Voltage - Forward (Vf) (Typ):	-
Current - DC Forward (If) (Max):	-
Vce Saturation (Max):	-
Operating Temperature:	-40°C ~ 105°C
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.268", 6.81mm Width)
Supplier Device Package:	8-SO Stretched
