ACPL-214-500E

Product image
Product thumb
Part No :

ACPL-214-500E

Manufacturer
Broadcom
VIGOR # :

4082929

Description
OPTOISOLATOR 3KV TRANS 4SOIC
Catalog
Optoisolators - Transistor, Photovoltaic Output
DataSheet
ACPL-214-500E PDF
Country of origin
-
Date code
-
ads
ACPL-214-500E Specifications
Type Description
Series:-
Package:Tape & Reel (TR)Cut Tape (CT)
Part Status:Active
Number of Channels:1
Voltage - Isolation:3000Vrms
Current Transfer Ratio (Min):20% @ 1mA
Current Transfer Ratio (Max):400% @ 1mA
Turn On / Turn Off Time (Typ):3µs, 3µs
Rise / Fall Time (Typ):2µs, 3µs
Input Type:AC, DC
Output Type:Transistor
Voltage - Output (Max):80V
Current - Output / Channel:50mA
Voltage - Forward (Vf) (Typ):1.2V
Current - DC Forward (If) (Max):50 mA
Vce Saturation (Max):400mV
Operating Temperature:-55°C ~ 110°C
Mounting Type:Surface Mount
Package / Case:4-SOIC (0.173", 4.40mm Width)
Supplier Device Package:4-SO
