ACPL-P454-500E

Part No :: ACPL-P454-500E

Manufacturer: Broadcom

VIGOR # :: 4082953

Description: OPTOISOLATOR 3.75KV TRANS 6SOIC

Catalog: Optoisolators - Transistor, Photovoltaic Output

DataSheet: ACPL-P454-500E PDF

Country of origin: -

Date code: -

ACPL-P454-500E Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)
Part Status:	Active
Number of Channels:	1
Voltage - Isolation:	3750Vrms
Current Transfer Ratio (Min):	25% @ 16mA
Current Transfer Ratio (Max):	60% @ 16mA
Turn On / Turn Off Time (Typ):	200ns, 300ns
Rise / Fall Time (Typ):	-
Input Type:	DC
Output Type:	Transistor
Voltage - Output (Max):	20V
Current - Output / Channel:	8mA
Voltage - Forward (Vf) (Typ):	1.5V
Current - DC Forward (If) (Max):	25 mA
Vce Saturation (Max):	-
Operating Temperature:	-55°C ~ 100°C
Mounting Type:	Surface Mount
Package / Case:	6-SOIC (0.268", 6.80mm Width)
Supplier Device Package:	6-SO Stretched
