HCPL-5761#200

Part No :: HCPL-5761#200

Manufacturer: Broadcom

Description: OPTOISO 1.5KV DARLINGTON 8-DIP

Catalog: Optoisolators - Transistor, Photovoltaic Output

DataSheet: HCPL-5761#200 PDF

Availability: 0 pieces

Current price of HCPL-5761#200 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

HCPL-5761#200 Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Active
Number of Channels:	1
Voltage - Isolation:	1500VDC
Current Transfer Ratio (Min):	-
Current Transfer Ratio (Max):	-
Turn On / Turn Off Time (Typ):	4µs, 8µs
Rise / Fall Time (Typ):	10µs, 0.5µs
Input Type:	AC, DC
Output Type:	Darlington
Voltage - Output (Max):	20V
Current - Output / Channel:	40mA
Voltage - Forward (Vf) (Typ):	-
Current - DC Forward (If) (Max):	-
Vce Saturation (Max):	-
Operating Temperature:	-55°C ~ 125°C
Mounting Type:	Through Hole
Package / Case:	8-DIP (0.300", 7.62mm)
Supplier Device Package:	8-DIP
