TCMT1600

Part No :: TCMT1600

Manufacturer: Vishay / Semiconductor - Opto Division

Description: OPTOISOLATOR 3.75KV TRANS 4-SOP

Catalog: Optoisolators - Transistor, Photovoltaic Output

DataSheet: TCMT1600 PDF

Availability: 6242 pieces

Unit Price: ~~$0.66000~~

Current price of TCMT1600 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

TCMT1600 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Number of Channels:	1
Voltage - Isolation:	3750Vrms
Current Transfer Ratio (Min):	80% @ 5mA
Current Transfer Ratio (Max):	300% @ 5mA
Turn On / Turn Off Time (Typ):	6µs, 5µs
Rise / Fall Time (Typ):	3µs, 4.7µs
Input Type:	AC, DC
Output Type:	Transistor
Voltage - Output (Max):	70V
Current - Output / Channel:	50mA
Voltage - Forward (Vf) (Typ):	1.35V
Current - DC Forward (If) (Max):	60 mA
Vce Saturation (Max):	300mV
Operating Temperature:	-40°C ~ 100°C
Mounting Type:	Surface Mount
Package / Case:	4-SOIC (0.173", 4.40mm Width)
Supplier Device Package:	4-SOP
