HCPL-5701

Product image
Product thumb
Part No :

HCPL-5701

Manufacturer
Broadcom
VIGOR # :

4084347

Description
OPTOISO 1.5KV DARLINGTON 8-DIP
Catalog
Optoisolators - Transistor, Photovoltaic Output
DataSheet
HCPL-5701 PDF
Country of origin
-
Date code
-
ads
HCPL-5701 Specifications
Type Description
Series:-
Package:Tube
Part Status:Active
Number of Channels:1
Voltage - Isolation:1500VDC
Current Transfer Ratio (Min):200% @ 5mA
Current Transfer Ratio (Max):-
Turn On / Turn Off Time (Typ):2µs, 8µs
Rise / Fall Time (Typ):-
Input Type:DC
Output Type:Darlington
Voltage - Output (Max):20V
Current - Output / Channel:40mA
Voltage - Forward (Vf) (Typ):1.4V
Current - DC Forward (If) (Max):10 mA
Vce Saturation (Max):110mV
Operating Temperature:-55°C ~ 125°C
Mounting Type:Through Hole
Package / Case:8-DIP (0.300", 7.62mm)
Supplier Device Package:8-DIP
