TLP2303(TPR,E

Part No :: TLP2303(TPR,E

Manufacturer: Toshiba Electronic Devices and Storage Corporation

VIGOR # :: 4085168

Description: X36 PB-F PHOTOCOUPLER SO6 TAPE &

Catalog: Optoisolators - Transistor, Photovoltaic Output

DataSheet: TLP2303(TPR,E PDF

Country of origin: -

Date code: -

TLP2303(TPR,E Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)
Part Status:	Active
Number of Channels:	1
Voltage - Isolation:	3750Vrms
Current Transfer Ratio (Min):	500% @ 5mA
Current Transfer Ratio (Max):	-
Turn On / Turn Off Time (Typ):	-
Rise / Fall Time (Typ):	-
Input Type:	DC
Output Type:	Transistor
Voltage - Output (Max):	18V
Current - Output / Channel:	80mA
Voltage - Forward (Vf) (Typ):	-
Current - DC Forward (If) (Max):	20 mA
Vce Saturation (Max):	-
Operating Temperature:	-40°C ~ 125°C
Mounting Type:	Surface Mount
Package / Case:	6-SOIC (0.179", 4.55mm Width), 5 Leads
Supplier Device Package:	6-SO, 5 Lead
