FOD053LR1

Part No :: FOD053LR1

Manufacturer: VIGOR

Description: LOGIC IC OUTPUT OPTOCOUPLER

Catalog: Optoisolators - Transistor, Photovoltaic Output

DataSheet: FOD053LR1 PDF

Availability: 11850 pieces

Unit Price: ~~$1.55000~~

Current price of FOD053LR1 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

FOD053LR1 Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Obsolete
Number of Channels:	2
Voltage - Isolation:	2500Vrms
Current Transfer Ratio (Min):	15% @ 16mA
Current Transfer Ratio (Max):	50% @ 16mA
Turn On / Turn Off Time (Typ):	1µs, 1µs (Max)
Rise / Fall Time (Typ):	-
Input Type:	DC
Output Type:	Transistor
Voltage - Output (Max):	7V
Current - Output / Channel:	8mA
Voltage - Forward (Vf) (Typ):	1.45V
Current - DC Forward (If) (Max):	25 mA
Vce Saturation (Max):	-
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOIC
