6N138SM

Part No :: 6N138SM

Manufacturer: Sanyo Semiconductor/ON Semiconductor

VIGOR # :: 4086286

Description: OPTOISO 5KV DARL W/BASE 8SMD

Catalog: Optoisolators - Transistor, Photovoltaic Output

DataSheet: 6N138SM PDF

Country of origin: -

Date code: -

6N138SM Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Number of Channels:	1
Voltage - Isolation:	5000Vrms
Current Transfer Ratio (Min):	300% @ 1.6mA
Current Transfer Ratio (Max):	-
Turn On / Turn Off Time (Typ):	1µs, 7.3µs
Rise / Fall Time (Typ):	-
Input Type:	DC
Output Type:	Darlington with Base
Voltage - Output (Max):	7V
Current - Output / Channel:	60mA
Voltage - Forward (Vf) (Typ):	1.3V
Current - DC Forward (If) (Max):	20 mA
Vce Saturation (Max):	-
Operating Temperature:	-40°C ~ 100°C
Mounting Type:	Surface Mount
Package / Case:	8-SMD, Gull Wing
Supplier Device Package:	8-SMD
