SFH601-2X007

Part No :: SFH601-2X007

Manufacturer: Vishay / Semiconductor - Opto Division

Description: OPTOISO 5.3KV TRANS W/BASE 6SMD

Catalog: Optoisolators - Transistor, Photovoltaic Output

DataSheet: SFH601-2X007 PDF

Availability: 0 pieces

Unit Price: ~~$0.00000~~

Current price of SFH601-2X007 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SFH601-2X007 Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Number of Channels:	1
Voltage - Isolation:	5300Vrms
Current Transfer Ratio (Min):	63% @ 10mA
Current Transfer Ratio (Max):	125% @ 10mA
Turn On / Turn Off Time (Typ):	3µs, 2.3µs
Rise / Fall Time (Typ):	2µs, 2µs
Input Type:	DC
Output Type:	Transistor with Base
Voltage - Output (Max):	100V
Current - Output / Channel:	50mA
Voltage - Forward (Vf) (Typ):	1.25V
Current - DC Forward (If) (Max):	60 mA
Vce Saturation (Max):	400mV
Operating Temperature:	-55°C ~ 100°C
Mounting Type:	Surface Mount
Package / Case:	6-SMD, Gull Wing
Supplier Device Package:	6-SMD
