PC3SF11YVZAH

Part No :: PC3SF11YVZAH

Manufacturer: Sharp Microelectronics

VIGOR # :: 4981997

Description: OPTOISOLATOR 5KV TRIAC DIP

Catalog: Optoisolators - Triac, SCR Output

DataSheet: PC3SF11YVZAH PDF

Country of origin: -

Date code: -

PC3SF11YVZAH Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Discontinued at Digi-Key
Output Type:	Triac
Zero Crossing Circuit:	No
Number of Channels:	1
Voltage - Isolation:	5000Vrms
Voltage - Off State:	600 V
Static dV/dt (Min):	1kV/µs
Current - LED Trigger (Ift) (Max):	10mA
Current - On State (It (RMS)) (Max):	100 mA
Current - Hold (Ih):	3.5mA
Turn On Time:	100µs (Max)
Voltage - Forward (Vf) (Typ):	1.2V
Current - DC Forward (If) (Max):	50 mA
Operating Temperature:	-30°C ~ 100°C
Mounting Type:	Through Hole
Package / Case:	6-DIP (0.400", 10.16mm), 5 Leads
Supplier Device Package:	6-DIP
Approval Agency:	BSI, CSA, DEMKO, FIMKO, SEMKO, UR, VDE
