B65843A0200B038

Part No :: B65843A0200B038

Manufacturer: TDK EPCOS

Description: FERRITE CORE EP 200NH T38 2PCS

Catalog: Ferrite Cores

DataSheet: B65843A0200B038 PDF

Availability: 0 pieces

Current price of B65843A0200B038 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

B65843A0200B038 Specifications

Type	Description
Series:	B65843A
Package:	Box
Part Status:	Active
Core Type:	EP
Supplier Device Package:	EP 13
Material:	T38
Diameter:	-
Inductance Factor (Al):	200 nH
Tolerance:	±4%
Gap:	Gapped
Effective Permeability (µe):	198
Initial Permeability (µi):	2300
Core Factor (ΣI/A) mm^-1:	1.24
Effective Length (le) mm:	24.2
Effective Area (Ae) mm²:	19.5
Minimum Core Cross Section (Amin) mm²:	14.9
Effective Magnetic Volume (Ve) mm³:	472
Finish:	Uncoated
Height:	6.50mm
Length:	12.80mm
Width:	9.00mm
