B65879A0000R049

Part No :: B65879A0000R049

Manufacturer: TDK EPCOS

Description: FERRITE CORE PQ 4.6UH N49 2PCS

Catalog: Ferrite Cores

DataSheet: B65879A0000R049 PDF

Availability: 126 pieces

Current price of B65879A0000R049 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

B65879A0000R049 Specifications

Type	Description
Series:	B65879A
Package:	Box
Part Status:	Active
Core Type:	PQ
Supplier Device Package:	PQ 32 x 20
Material:	N49
Diameter:	-
Inductance Factor (Al):	4.6 µH
Tolerance:	-20%, +30%
Gap:	Ungapped
Effective Permeability (µe):	1150
Initial Permeability (µi):	1500
Core Factor (ΣI/A) mm^-1:	0.314
Effective Length (le) mm:	48.4
Effective Area (Ae) mm²:	154.2
Minimum Core Cross Section (Amin) mm²:	127.5
Effective Magnetic Volume (Ve) mm³:	7460
Finish:	Uncoated
Height:	10.25mm
Length:	32.00mm
Width:	22.00mm
