PCN2-S5-D15-S

Image is for reference,
please contact us to get the real picture

Part No :: PCN2-S5-D15-S

Manufacturer: CUI Inc.

Description: DC DC CONVERTER +/-15V 2W

Catalog: DC DC Converters

DataSheet: PCN2-S5-D15-S PDF

Availability: 1926 pieces

Unit Price: ~~$5.99000~~

Current price of PCN2-S5-D15-S is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

PCN2-S5-D15-S Specifications

Type	Description
Series:	PCN2-S (2W)
Package:	Tube
Part Status:	Active
Type:	Isolated Module
Number of Outputs:	2
Voltage - Input (Min):	4.5V
Voltage - Input (Max):	5.5V
Voltage - Output 1:	15V
Voltage - Output 2:	-15V
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	67mA, 67mA
Power (Watts):	2 W
Voltage - Isolation:	1 kV
Applications:	ITE (Commercial)
Features:	SCP
Operating Temperature:	-40°C ~ 100°C
Efficiency:	86%
Mounting Type:	Through Hole
Package / Case:	6-SIP Module, 5 Leads
Size / Dimension:	0.77" L x 0.28" W x 0.40" H (19.6mm x 7.2mm x 10.2mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	EN
Standard Number:	55032 Class A
