AM3G-0505SH30-NZ

Part No :: AM3G-0505SH30-NZ

Manufacturer: DComponents

VIGOR # :: 4115444

Description: DC DC CONVERTER 5V 2.5W

Catalog: DC DC Converters

DataSheet: AM3G-0505SH30-NZ PDF

Country of origin: -

Date code: -

AM3G-0505SH30-NZ Specifications

Type	Description
Series:	AM3G-NZ (3W)
Package:	Tube
Part Status:	Active
Type:	Isolated Module
Number of Outputs:	1
Voltage - Input (Min):	4.5V
Voltage - Input (Max):	9V
Voltage - Output 1:	5V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	500mA
Power (Watts):	2.5 W
Voltage - Isolation:	3 kV
Applications:	ITE (Commercial)
Features:	Remote On/Off
Operating Temperature:	-40°C ~ 100°C (With Derating)
Efficiency:	73%
Mounting Type:	Through Hole
Package / Case:	8-SIP Module, 7 Leads
Size / Dimension:	0.87" L x 0.37" W x 0.49" H (22.0mm x 9.5mm x 12.5mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
PRMC3-D5-S5-S Match 100%	CUI Inc. DC DC CONVERTER 5V 2.5W	AM3G-0505SH30-NZ vs PRMC3-D5-S5-S
PRM3W-E12-S5-S Match 87%	CUI Inc. DC-DC ISOLATED, 3 W, 4.5~36 VDC	AM3G-0505SH30-NZ vs PRM3W-E12-S5-S
UWF1205S-3WR3 Match 87%	Mornsun DC DC CONVERTER,3W,5VDC	AM3G-0505SH30-NZ vs UWF1205S-3WR3
PQMC3-D5-S5-S Match 85%	CUI Inc. DC DC CONVERTER 5V 3W	AM3G-0505SH30-NZ vs PQMC3-D5-S5-S
EDL03-12S05W Match 79%	P-Duke Technology, Inc. DC DC CONVERTER 5V 3W	AM3G-0505SH30-NZ vs EDL03-12S05W
IZ0505SA Match 79%	XP Power DC DC CONVERTER 5V 3W	AM3G-0505SH30-NZ vs IZ0505SA

Please confirm the specifications of the products when ordering.
MOQ means the minimum order quantity required to purchase each parts.
If you have special order instructions,please note it on the ordering pages.
The Pre-Shipment Inspection (PSI) will be applied.
You can email us to change the order details before shipment.
Orders cannot be canceled after shipping the packages.

TT in advance (bank transfer), Credit Card, PayPal can be chosen.
Cash transfer only. (Transfer with checks and bills are not accepted.)
Customer is responsible for paying all possible charges,including sales tax, VAT and customs charges,etc.
If you need the detailed invoice or tax ID,please email us.

FedEx, DHL, and UPS can be selected.
You can select whether to charge shipping fee by your shipping account or to charge by our side.
Please confirm with the logistics company in advance if you are in a remote area. (It may cost extra fees (35-50 USD) for delivery at those areas.)
The shopping cart will automatically calculate the shipping cost.
Delivery time: At the same day (Order deadline is 2pm, HK Time).
Delivery date: usually 2 to 7 working days.
It is unable to appoint a date of delivery.
Tracking number will be sent once your order has been shipped. (It may take up to 24 hours before carriers display the info.)

In Stock: 1381

Shipped from

HK warehouse

Expected Shipping Date

Sep 01 - Sep 05 2026

Pricing(USD)

Quantity	Unit Price	Ext. Price
1	~~$10.6300~~	~~$10.63~~

Current price of AM3G-0505SH30-NZ is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
