AM3G-0509SH30-NZ

Part No :: AM3G-0509SH30-NZ

Manufacturer: DComponents

VIGOR # :: 4115534

Description: DC DC CONVERTER 9V 2.5W

Catalog: DC DC Converters

DataSheet: AM3G-0509SH30-NZ PDF

Country of origin: -

Date code: -

AM3G-0509SH30-NZ Specifications

Type	Description
Series:	AM3G-NZ (3W)
Package:	Tube
Part Status:	Active
Type:	Isolated Module
Number of Outputs:	1
Voltage - Input (Min):	4.5V
Voltage - Input (Max):	9V
Voltage - Output 1:	9V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	278mA
Power (Watts):	2.5 W
Voltage - Isolation:	3 kV
Applications:	ITE (Commercial)
Features:	Remote On/Off
Operating Temperature:	-40°C ~ 100°C (With Derating)
Efficiency:	74%
Mounting Type:	Through Hole
Package / Case:	8-SIP Module, 7 Leads
Size / Dimension:	0.87" L x 0.37" W x 0.49" H (22.0mm x 9.5mm x 12.5mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
HEA2-5S9 Match 76%	Daburn DC DC CONVERTER 9V 2W	AM3G-0509SH30-NZ vs HEA2-5S9
PRM3W-E12-S12-S Match 65%	CUI Inc. DC-DC ISOLATED, 3 W, 4.5~36 VDC	AM3G-0509SH30-NZ vs PRM3W-E12-S12-S
AM3G-0509S-NZ Match 91%	DComponents DC DC CONVERTER 9V 2.5W	AM3G-0509SH30-NZ vs AM3G-0509S-NZ
PRMC3-D5-S9-S Match 100%	CUI Inc. DC DC CONVERTER 9V 2.5W	AM3G-0509SH30-NZ vs PRMC3-D5-S9-S
UWF1212S-3WR3 Match 65%	Mornsun DC DC CONVERTER,3W,12VDC	AM3G-0509SH30-NZ vs UWF1212S-3WR3
PQMC3-D5-S9-S Match 85%	CUI Inc. DC DC CONVERTER 9V 3W	AM3G-0509SH30-NZ vs PQMC3-D5-S9-S
