AM3N-0503SH52Z

Part No :: AM3N-0503SH52Z

Manufacturer: DComponents

VIGOR # :: 4120840

Description: DC DC CONVERTER 3.3V 3W

Catalog: DC DC Converters

DataSheet: AM3N-0503SH52Z PDF

Country of origin: -

Date code: -

AM3N-0503SH52Z Specifications

Type	Description
Series:	AM3N-S-Z (3W)
Package:	Tube
Part Status:	Active
Type:	Isolated Module
Number of Outputs:	1
Voltage - Input (Min):	4.5V
Voltage - Input (Max):	5.5V
Voltage - Output 1:	3.3V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	600mA
Power (Watts):	3 W
Voltage - Isolation:	5.2 kV
Applications:	ITE (Commercial)
Features:	-
Operating Temperature:	-40°C ~ 85°C
Efficiency:	58%
Mounting Type:	Through Hole
Package / Case:	24-DIP Module, 6 Leads
Size / Dimension:	1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	CE
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
MPP03-05S3P3B Match 75%	P-Duke Technology, Inc. ISOLATED / 3W/ VOUT:3.3	AM3N-0503SH52Z vs MPP03-05S3P3B
REM3-053.3S/A/CTRL Match 78%	RECOM Power DC DC CONVERTER 3.3V 3W	AM3N-0503SH52Z vs REM3-053.3S/A/CTRL
THM 3-0510 Match 75%	TRACO Power DC DC CONVERTER 3.3V 3.3W	AM3N-0503SH52Z vs THM 3-0510
THM 3-0510WI Match 75%	TRACO Power DC DC CONVERTER 3.3V 3.3W	AM3N-0503SH52Z vs THM 3-0510WI
AM3N-0505SH52Z Match 64%	DComponents DC DC CONVERTER 5V 3W	AM3N-0503SH52Z vs AM3N-0505SH52Z
AM3N-0503SH30Z Match 93%	DComponents DC DC CONVERTER 3.3V 3W	AM3N-0503SH52Z vs AM3N-0503SH30Z

Please confirm the specifications of the products when ordering.
MOQ means the minimum order quantity required to purchase each parts.
If you have special order instructions,please note it on the ordering pages.
The Pre-Shipment Inspection (PSI) will be applied.
You can email us to change the order details before shipment.
Orders cannot be canceled after shipping the packages.

TT in advance (bank transfer), Credit Card, PayPal can be chosen.
Cash transfer only. (Transfer with checks and bills are not accepted.)
Customer is responsible for paying all possible charges,including sales tax, VAT and customs charges,etc.
If you need the detailed invoice or tax ID,please email us.

FedEx, DHL, and UPS can be selected.
You can select whether to charge shipping fee by your shipping account or to charge by our side.
Please confirm with the logistics company in advance if you are in a remote area. (It may cost extra fees (35-50 USD) for delivery at those areas.)
The shopping cart will automatically calculate the shipping cost.
Delivery time: At the same day (Order deadline is 2pm, HK Time).
Delivery date: usually 2 to 7 working days.
It is unable to appoint a date of delivery.
Tracking number will be sent once your order has been shipped. (It may take up to 24 hours before carriers display the info.)

In Stock: 760

Shipped from

HK warehouse

Expected Shipping Date

Jul 22 - Jul 26 2026

Pricing(USD)

Quantity	Unit Price	Ext. Price
1	~~$12.6300~~	~~$12.63~~

Current price of AM3N-0503SH52Z is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com

Hot Products

PT5026A
