AM1/4S-0503SH30Z

Part No :: AM1/4S-0503SH30Z

Manufacturer: DComponents

VIGOR # :: 4125232

Description: DC DC CONVERTER 3.3V 250MW

Catalog: DC DC Converters

DataSheet: AM1/4S-0503SH30Z PDF

Country of origin: -

Date code: -

AM1/4S-0503SH30Z Specifications

Type	Description
Series:	AM1/4S-Z (0.25W)
Package:	Tube
Part Status:	Active
Type:	Isolated Module
Number of Outputs:	1
Voltage - Input (Min):	4.5V
Voltage - Input (Max):	5.5V
Voltage - Output 1:	3.3V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	75.7mA
Power (Watts):	250 mW
Voltage - Isolation:	3 kV
Applications:	ITE (Commercial)
Features:	-
Operating Temperature:	-40°C ~ 85°C
Efficiency:	64%
Mounting Type:	Through Hole
Package / Case:	4-SIP Module
Size / Dimension:	0.46" L x 0.24" W x 0.40" H (11.7mm x 6.0mm x 9.7mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	CE
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
AM1/4SS-0503S-NZ Match 91%	DComponents DC DC CONVERTER 3.3V 251MW	AM1/4S-0503SH30Z vs AM1/4SS-0503S-NZ
RM-053.3S/P Match 86%	RECOM Power DC DC CONVERTER 3.3V 250MW	AM1/4S-0503SH30Z vs RM-053.3S/P
AM1/4S-0503SZ Match 86%	DComponents DC DC CONVERTER 3.3V 250MW	AM1/4S-0503SH30Z vs AM1/4S-0503SZ
RM-053.3S/HP Match 95%	RECOM Power DC DC CONVERTER 3.3V 250MW	AM1/4S-0503SH30Z vs RM-053.3S/HP
IK0503SA Match 86%	XP Power DC DC CONVERTER 3.3V 250MW	AM1/4S-0503SH30Z vs IK0503SA
RM-053.3S/H Match 95%	RECOM Power DC DC CONVERTER 3.3V 250MW	AM1/4S-0503SH30Z vs RM-053.3S/H
