BTB05-03S80S

Part No :: BTB05-03S80S

Manufacturer: Bellnix Co., LTD.

VIGOR # :: 4134938

Description: DC DC CONVERTER 3.3V 2.6W

Catalog: DC DC Converters

DataSheet: BTB05-03S80S PDF

Current price of BTB05-03S80S is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

BTB05-03S80S Specifications

Type	Description
Series:	BTB (3W)
Package:	Bulk
Part Status:	Active
Type:	Isolated Module
Number of Outputs:	1
Voltage - Input (Min):	4.5V
Voltage - Input (Max):	9V
Voltage - Output 1:	3.3V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	800mA
Power (Watts):	2.6 W
Voltage - Isolation:	500 V
Applications:	ITE (Commercial)
Features:	Adjustable Output, Remote On/Off
Operating Temperature:	-40°C ~ 85°C (With Derating)
Efficiency:	73%
Mounting Type:	Surface Mount
Package / Case:	10-SMD Module, 7 Leads
Size / Dimension:	0.91" L x 0.65" W x 0.33" H (23.2mm x 16.6mm x 8.5mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	cUL, UL
Standard Number:	-

Please confirm the specifications of the products when ordering.
