AM1DE-2412SZ

Part No :: AM1DE-2412SZ

Manufacturer: DComponents

VIGOR # :: 4137633

Description: DC DC CONVERTER 12V 1W

Catalog: DC DC Converters

DataSheet: AM1DE-2412SZ PDF

Country of origin: -

Date code: -

AM1DE-2412SZ Specifications

Type	Description
Series:	AM1DE-Z (1W)
Package:	Tube
Part Status:	Active
Type:	Isolated Module
Number of Outputs:	1
Voltage - Input (Min):	21.6V
Voltage - Input (Max):	26.4V
Voltage - Output 1:	12V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	83mA
Power (Watts):	1 W
Voltage - Isolation:	1.5 kV
Applications:	ITE (Commercial)
Features:	-
Operating Temperature:	-40°C ~ 95°C (With Derating)
Efficiency:	80%
Mounting Type:	Through Hole
Package / Case:	7-SIP Module, 4 Leads
Size / Dimension:	0.76" L x 0.24" W x 0.39" H (19.5mm x 6.0mm x 10.0mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	CE
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
TBA 1-2412HI Match 90%	TRACO Power DC DC CONVERTER 12V 1W	AM1DE-2412SZ vs TBA 1-2412HI
PEM1-S24-S12-S Match 91%	CUI Inc. DC DC CONVERTER 12V 1W	AM1DE-2412SZ vs PEM1-S24-S12-S
B2412LS-1WR3 Match 100%	Mornsun DC DC CONVERTER 12V 1W	AM1DE-2412SZ vs B2412LS-1WR3
ITV2412SA Match 91%	XP Power DC DC CONVERTER 12V 1W	AM1DE-2412SZ vs ITV2412SA
ITB2412S Match 100%	XP Power DC DC CONVERTER 12V 1W	AM1DE-2412SZ vs ITB2412S
F2412S-1WR3 Match 91%	Mornsun DC DC CONVERTER 12V 1W	AM1DE-2412SZ vs F2412S-1WR3

Please confirm the specifications of the products when ordering.
MOQ means the minimum order quantity required to purchase each parts.
If you have special order instructions,please note it on the ordering pages.
The Pre-Shipment Inspection (PSI) will be applied.
You can email us to change the order details before shipment.
Orders cannot be canceled after shipping the packages.

TT in advance (bank transfer), Credit Card, PayPal can be chosen.
Cash transfer only. (Transfer with checks and bills are not accepted.)
Customer is responsible for paying all possible charges,including sales tax, VAT and customs charges,etc.
If you need the detailed invoice or tax ID,please email us.

FedEx, DHL, and UPS can be selected.
You can select whether to charge shipping fee by your shipping account or to charge by our side.
Please confirm with the logistics company in advance if you are in a remote area. (It may cost extra fees (35-50 USD) for delivery at those areas.)
The shopping cart will automatically calculate the shipping cost.
Delivery time: At the same day (Order deadline is 2pm, HK Time).
Delivery date: usually 2 to 7 working days.
It is unable to appoint a date of delivery.
Tracking number will be sent once your order has been shipped. (It may take up to 24 hours before carriers display the info.)

In Stock: 465

Shipped from

HK warehouse

Expected Shipping Date

Sep 06 - Sep 10 2026

Pricing(USD)

Quantity	Unit Price	Ext. Price
1	~~$4.5700~~	~~$4.57~~

Current price of AM1DE-2412SZ is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
