PT6323R

Part No :: PT6323R

Manufacturer: VIGOR

VIGOR # :: 4155709

Description: SWITCHING REGULATOR

Catalog: DC DC Converters

DataSheet: PT6323R PDF

Country of origin: -

Date code: -

PT6323R Specifications

Type	Description
Series:	PT6320
Package:	Tray
Part Status:	Obsolete
Type:	Non-Isolated PoL Module
Number of Outputs:	1
Voltage - Input (Min):	7V
Voltage - Input (Max):	26V
Voltage - Output 1:	3.3V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	3A
Power (Watts):	-
Voltage - Isolation:	-
Applications:	ITE (Commercial)
Features:	-
Operating Temperature:	-40°C ~ 85°C
Efficiency:	84%
Mounting Type:	Through Hole
Package / Case:	12-SIP Module
Size / Dimension:	-
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
R-733.3P Match 100%	RECOM Power DC DC CONVERTER 3.3V 9.9W	PT6323R vs R-733.3P
R-743.3P Match 82%	RECOM Power DC DC CONVERTER 3.3V 13W	PT6323R vs R-743.3P
R-723.3P Match 74%	RECOM Power DC DC CONVERTER 3.3V 6.6W	PT6323R vs R-723.3P
PT6323N Match 100%	VIGOR SWITCHING REGLTR, VOLTAGE-MODE	PT6323R vs PT6323N
PT6203N Match 74%	Texas Instruments DC DC CONVERTER 3.3V	PT6323R vs PT6203N
PT6223N Match 74%	Texas Instruments DC DC CONVERTER 3.3V	PT6323R vs PT6223N
