PT7714C

Image is for reference,
please contact us to get the real picture

Part No :: PT7714C

Manufacturer: VIGOR

Description: SWITCHING REGULATOR

Catalog: DC DC Converters

Shipped from: HK warehouse

Expected Shipping Date: Oct 02 - Oct 06 2025

DataSheet: PT7714C PDF

Availability: 115 pieces

Unit Price: ~~$45.14000~~

Current price of PT7714C is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

PT7714C Specifications

Type	Description
Series:	Excalibur™ PT7714
Package:	Tray
Part Status:	Obsolete
Type:	Non-Isolated PoL Module
Number of Outputs:	1
Voltage - Input (Min):	3.1V
Voltage - Input (Max):	3.6V
Voltage - Output 1:	0.8 ~ 1.575V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	20A
Power (Watts):	-
Voltage - Isolation:	-
Applications:	ITE (Commercial)
Features:	Remote On/Off, OCP
Operating Temperature:	-40°C ~ 85°C
Efficiency:	80%
Mounting Type:	Surface Mount
Package / Case:	27-SMD Module
Size / Dimension:	3.00" L x 1.19" W x 0.50" H (76.2mm x 30.2mm x 12.7mm)
Supplier Device Package:	-
Control Features:	Enable, Active High
Approval Agency:	-
Standard Number:	-
