PXG-M20-48WS05

Part No :: PXG-M20-48WS05

Manufacturer: TDK-Lambda, Inc.

VIGOR # :: 4160128

Description: DC DC CONVERTER 5V 20W

Catalog: DC DC Converters

DataSheet: PXG-M20-48WS05 PDF

Country of origin: -

Date code: -

PXG-M20-48WS05 Specifications

Type	Description
Series:	PXG-M (20W)
Package:	Tube
Part Status:	Active
Type:	Isolated Module
Number of Outputs:	1
Voltage - Input (Min):	18V
Voltage - Input (Max):	75V
Voltage - Output 1:	5V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	4A
Power (Watts):	20 W
Voltage - Isolation:	5 kV
Applications:	ITE (Commercial), Medical
Features:	Adjustable Output
Operating Temperature:	-40°C ~ 105°C (With Derating)
Efficiency:	89.5%
Mounting Type:	Through Hole
Package / Case:	6-DIP Module
Size / Dimension:	1.60" L x 1.00" W x 0.40" H (40.6mm x 25.4mm x 10.2mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	CE
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
FED20-48S05W Match 86%	P-Duke Technology, Inc. DC DC CONVERTER 5V 20W	PXG-M20-48WS05 vs FED20-48S05W
JTM2048S05 Match 86%	XP Power DC DC CONVERTER 5V 20W	PXG-M20-48WS05 vs JTM2048S05
REM20-4805SW/P Match 100%	RECOM Power DC DC CONVERTER 5V 20W	PXG-M20-48WS05 vs REM20-4805SW/P
EC7BW18-72S05 Match 93%	Cincon DC DC CONVERTER 5V 20W	PXG-M20-48WS05 vs EC7BW18-72S05
EC7BW18-72S05-EDRT Match 93%	Cincon DC-DC CONV	PXG-M20-48WS05 vs EC7BW18-72S05-EDRT
EC7BW18-72S05-ECRT Match 93%	Cincon DC-DC CONV	PXG-M20-48WS05 vs EC7BW18-72S05-ECRT

Please confirm the specifications of the products when ordering.
MOQ means the minimum order quantity required to purchase each parts.
If you have special order instructions,please note it on the ordering pages.
The Pre-Shipment Inspection (PSI) will be applied.
You can email us to change the order details before shipment.
Orders cannot be canceled after shipping the packages.

TT in advance (bank transfer), Credit Card, PayPal can be chosen.
Cash transfer only. (Transfer with checks and bills are not accepted.)
Customer is responsible for paying all possible charges,including sales tax, VAT and customs charges,etc.
If you need the detailed invoice or tax ID,please email us.

FedEx, DHL, and UPS can be selected.
You can select whether to charge shipping fee by your shipping account or to charge by our side.
Please confirm with the logistics company in advance if you are in a remote area. (It may cost extra fees (35-50 USD) for delivery at those areas.)
The shopping cart will automatically calculate the shipping cost.
Delivery time: At the same day (Order deadline is 2pm, HK Time).
Delivery date: usually 2 to 7 working days.
It is unable to appoint a date of delivery.
Tracking number will be sent once your order has been shipped. (It may take up to 24 hours before carriers display the info.)

In Stock: 852

Shipped from

HK warehouse

Expected Shipping Date

Jul 28 - Aug 01 2026

Pricing(USD)

Quantity	Unit Price	Ext. Price
1	~~$90.5900~~	~~$90.59~~

Current price of PXG-M20-48WS05 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
