EHD-RD3470

Part No :: EHD-RD3470

Manufacturer: Panasonic

VIGOR # :: 4986289

Description: DC DC CONVERTER -32V 3W

Catalog: DC DC Converters

DataSheet: EHD-RD3470 PDF

Country of origin: -

Date code: -

EHD-RD3470 Specifications

Type	Description
Series:	EHD-RD
Package:	Tray
Part Status:	Obsolete
Type:	Non-Isolated PoL Module
Number of Outputs:	1
Voltage - Input (Min):	-113V
Voltage - Input (Max):	-170V
Voltage - Output 1:	-32V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	100mA
Power (Watts):	3 W
Voltage - Isolation:	-
Applications:	ITE (Commercial)
Features:	-
Operating Temperature:	-25°C ~ 80°C
Efficiency:	78%
Mounting Type:	Through Hole
Package / Case:	10-SIP Module, 5 Leads
Size / Dimension:	1.11" L x 0.31" W x 0.70" H (28.2mm x 8.0mm x 17.9mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	-
