VI-22J-EW-F3 – Vicor 100W Isolated Module

Part No :: VI-22J-EW-F3

Manufacturer: Vicor

VIGOR # :: 4986553

Description: DC DC CONVERTER 36V 100W

Catalog: DC DC Converters

DataSheet: VI-22J-EW-F3 PDF

Country of origin: -

Date code: -

Product Description

Vicor's VI-22J-EW-F3 is a 100W isolated module in the VI-200 family.

The module accepts a 21V to 56V input range and provides a stable, well-regulated 36V output, delivering up to 2.78A of output current.

Full specifications are listed below — submit an RFQ for today's best price.

VI-22J-EW-F3 Specifications

Type	Description
Series:	VI-200™ (100W)
Package:	Bulk
Part Status:	Active
Type:	Isolated Module
Number of Outputs:	1
Voltage - Input (Min):	21V
Voltage - Input (Max):	56V
Voltage - Output 1:	36V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	2.78A
Power (Watts):	100 W
Voltage - Isolation:	3 kV
Applications:	ITE (Commercial)
Features:	OCP, OTP, OVP, SCP
Operating Temperature:	-10°C ~ 85°C
Efficiency:	88%
Mounting Type:	Through Hole
Package / Case:	Full Brick
Size / Dimension:	4.60" L x 1.86" W x 0.79" H (116.8mm x 47.2mm x 20.1mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
VI-22J-CW Match 100%	Vicor DC DC CONVERTER 36V 100W	VI-22J-EW-F3 vs VI-22J-CW
VI-22J-EW Match 100%	Vicor DC DC CONVERTER 36V 100W	VI-22J-EW-F3 vs VI-22J-EW
VI-22J-MW Match 100%	Vicor DC DC CONVERTER 36V 100W	VI-22J-EW-F3 vs VI-22J-MW
VI-22J-CW-F4 Match 100%	Vicor DC DC CONVERTER 36V 100W	VI-22J-EW-F3 vs VI-22J-CW-F4
VI-22J-MW-F4 Match 100%	Vicor DC DC CONVERTER 36V 100W	VI-22J-EW-F3 vs VI-22J-MW-F4
VI-22J-EW-F1 Match 100%	Vicor DC DC CONVERTER 36V 100W	VI-22J-EW-F3 vs VI-22J-EW-F1
