PT5047N

Part No :: PT5047N

Manufacturer: Texas Instruments

VIGOR # :: 5010791

Description: DC DC CONVERTER 18V

Catalog: DC DC Converters

DataSheet: PT5047N PDF

Country of origin: -

Date code: -

PT5047N Specifications

Type	Description
Series:	PT5040
Package:	Tray
Part Status:	Obsolete
Type:	Non-Isolated PoL Module
Number of Outputs:	1
Voltage - Input (Min):	4.75V
Voltage - Input (Max):	14V
Voltage - Output 1:	18V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	600mA
Power (Watts):	-
Voltage - Isolation:	-
Applications:	ITE (Commercial)
Features:	-
Operating Temperature:	-20°C ~ 85°C
Efficiency:	85%
Mounting Type:	Through Hole
Package / Case:	3-SIP Module
Size / Dimension:	-
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
PT5047H Match 100%	VIGOR SWITCHING REGLTR, VOLTAGE-MODE	PT5047N vs PT5047H
PT5049N Match 74%	VIGOR SWITCHING REGLTR, VOLTAGE-MODE	PT5047N vs PT5049N
PT5042H Match 61%	Texas Instruments DC DC CONVERTER 15V	PT5047N vs PT5042H
PT5042N Match 61%	Texas Instruments DC DC CONVERTER 15V	PT5047N vs PT5042N
PT5042S Match 61%	Texas Instruments DC DC CONVERTER 15V	PT5047N vs PT5042S
