PTN78000HAZT

Part No :: PTN78000HAZT

Manufacturer: Texas Instruments

VIGOR # :: 5018288

Description: DC DC CONVERTER 11.85-22V

Catalog: DC DC Converters

DataSheet: PTN78000HAZT PDF

Country of origin: -

Date code: -

PTN78000HAZT Specifications

Type	Description
Series:	PTN78000H
Package:	Tape & Reel (TR)
Part Status:	Obsolete
Type:	Non-Isolated PoL Module
Number of Outputs:	1
Voltage - Input (Min):	15V
Voltage - Input (Max):	36V
Voltage - Output 1:	11.85 ~ 22V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	1.5A
Power (Watts):	-
Voltage - Isolation:	-
Applications:	ITE (Commercial)
Features:	OCP, OTP, UVLO
Operating Temperature:	-40°C ~ 85°C
Efficiency:	94%
Mounting Type:	Surface Mount
Package / Case:	5-SMD Module
Size / Dimension:	0.75" L x 0.50" W x 0.36" H (19.1mm x 12.7mm x 9.1mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	-
