PT5048M

Part No :: PT5048M

Manufacturer: Texas Instruments

VIGOR # :: 5024294

Description: DC DC CONVERTER 12.6V

Catalog: DC DC Converters

DataSheet: PT5048M PDF

Country of origin: -

Date code: -

PT5048M Specifications

Type	Description
Series:	PT5040
Package:	Tray
Part Status:	Obsolete
Type:	Non-Isolated PoL Module
Number of Outputs:	1
Voltage - Input (Min):	4.75V
Voltage - Input (Max):	11.6V
Voltage - Output 1:	12.6V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	1A
Power (Watts):	-
Voltage - Isolation:	-
Applications:	ITE (Commercial)
Features:	-
Operating Temperature:	-20°C ~ 85°C
Efficiency:	85%
Mounting Type:	Through Hole, Right Angle
Package / Case:	3-SIP Module
Size / Dimension:	-
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
PT5048A Match 100%	VIGOR SWITCHING REGLTR, VOLTAGE-MODE	PT5048M vs PT5048A
PT5042A Match 58%	Texas Instruments DC DC CONVERTER 15V	PT5048M vs PT5042A
PT5042M Match 58%	Texas Instruments DC DC CONVERTER 15V	PT5048M vs PT5042M
78SP117HC Match 59%	Texas Instruments DC DC CONVERTER 17V	PT5048M vs 78SP117HC
