VI-J5R-MX-F1 – Vicor 75W Isolated Module

Part No :: VI-J5R-MX-F1

Manufacturer: Vicor

VIGOR # :: 5028038

Description: DC DC CONVERTER 7.5V 75W

Catalog: DC DC Converters

DataSheet: VI-J5R-MX-F1 PDF

Country of origin: -

Date code: -

Product Description

The VI-J5R-MX-F1 is a 75W isolated module in the VI-J00 family, engineered by Vicor for high-density power conversion.

It converts a 100V–200V input into a regulated 7.5V output, delivering up to 10A of output current.

Check the detailed VI-J5R-MX-F1 specification table below and request a quote to secure inventory and pricing.

VI-J5R-MX-F1 Specifications

Type	Description
Series:	VI-J00™ (75W)
Package:	Bulk
Part Status:	Active
Type:	Isolated Module
Number of Outputs:	1
Voltage - Input (Min):	100V
Voltage - Input (Max):	200V
Voltage - Output 1:	7.5V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	10A
Power (Watts):	75 W
Voltage - Isolation:	3 kV
Applications:	ITE (Commercial)
Features:	OCP, SCP
Operating Temperature:	-55°C ~ 100°C
Efficiency:	90%
Mounting Type:	Through Hole
Package / Case:	Half Brick
Size / Dimension:	2.28" L x 1.86" W x 0.79" H (57.9mm x 47.2mm x 20.1mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
VI-J5R-MX-F2 Match 100%	Vicor DC DC CONVERTER 7.5V 75W	VI-J5R-MX-F1 vs VI-J5R-MX-F2
VI-J5M-MW-B1 Match 66%	Vicor DC DC CONVERTER 10V 100W	VI-J5R-MX-F1 vs VI-J5M-MW-B1
VI-J70-MY-F3 Match 52%	Vicor DC DC CONVERTER 5V 50W	VI-J5R-MX-F1 vs VI-J70-MY-F3
VI-J5R-MX Match 100%	Vicor DC DC CONVERTER 7.5V 75W	VI-J5R-MX-F1 vs VI-J5R-MX
VI-J5M-MW-F1 Match 66%	Vicor DC DC CONVERTER 10V 100W	VI-J5R-MX-F1 vs VI-J5M-MW-F1
VI-J5M-MW-F3 Match 66%	Vicor DC DC CONVERTER 10V 100W	VI-J5R-MX-F1 vs VI-J5M-MW-F3
