PT5103A

Part No :: PT5103A

Manufacturer: Texas Instruments

VIGOR # :: 5035094

Description: DC DC CONVERTER 3.3V 3W

Catalog: DC DC Converters

DataSheet: PT5103A PDF

Country of origin: -

Date code: -

PT5103A Specifications

Type	Description
Series:	PT5100
Package:	Tray
Part Status:	Obsolete
Type:	Linear Regulator Replacement
Number of Outputs:	1
Voltage - Input (Min):	9V
Voltage - Input (Max):	26V
Voltage - Output 1:	3.3V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	1A
Power (Watts):	3 W
Voltage - Isolation:	-
Applications:	ITE (Commercial)
Features:	OCP, OTP
Operating Temperature:	-40°C ~ 85°C
Efficiency:	82%
Mounting Type:	Through Hole, Right Angle
Package / Case:	3-SIP Module
Size / Dimension:	1.00" L x 1.02" W x 0.38" H (25.4mm x 25.9mm x 9.7mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
R-78B2.5-1.0L Match 65%	RECOM Power DC DC CONVERTER 2.5V 2.5W	PT5103A vs R-78B2.5-1.0L
V7803-1000R Match 97%	CUI Inc. DC DC CONVERTER 3.3V 3.3W	PT5103A vs V7803-1000R
PT5103M Match 100%	Texas Instruments DC DC CONVERTER 3.3V 3W	PT5103A vs PT5103M
