PT5806C

Part No :: PT5806C

Manufacturer: Texas Instruments

VIGOR # :: 5038578

Description: DC DC CONVERTER 1V

Catalog: DC DC Converters

DataSheet: PT5806C PDF

Country of origin: -

Date code: -

PT5806C Specifications

Type	Description
Series:	Excalibur™ PT5800
Package:	Tray
Part Status:	Obsolete
Type:	Non-Isolated PoL Module
Number of Outputs:	1
Voltage - Input (Min):	4.5V
Voltage - Input (Max):	5.5V
Voltage - Output 1:	1V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	18A
Power (Watts):	-
Voltage - Isolation:	-
Applications:	ITE (Commercial)
Features:	OCP, OTP
Operating Temperature:	-40°C ~ 85°C
Efficiency:	84%
Mounting Type:	Surface Mount
Package / Case:	18-SMD Module
Size / Dimension:	2.00" L x 1.19" W x 0.31" H (50.8mm x 30.2mm x 7.9mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	-
