SP2-DC36V

Image is for reference,
please contact us to get the real picture

Part No :: SP2-DC36V

Manufacturer: Panasonic

Description: RELAY GEN PURPOSE DPDT 15A 36V

Catalog: Power Relays, Over 2 Amps

DataSheet: SP2-DC36V PDF

Availability: 0 pieces

Unit Price: ~~$26.86600~~

Current price of SP2-DC36V is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SP2-DC36V Specifications

Type	Description
Series:	SP
Package:	Tube
Part Status:	Active
Mounting Type:	Socketable
Coil Voltage:	36VDC
Contact Form:	DPDT (2 Form C)
Contact Rating (Current):	15 A
Switching Voltage:	250VAC, 30VDC - Max
Coil Current:	8.3 mA
Coil Type:	Non Latching
Features:	-
Termination Style:	Plug In, Quick Connect - 0.187" (4.7mm)
Seal Rating:	-
Coil Insulation:	-
Must Operate Voltage:	25.2 VDC
Must Release Voltage:	3.6 VDC
Operate Time:	30 ms
Release Time:	20 ms
Operating Temperature:	-50°C ~ 60°C
Contact Material:	Silver Tin Oxide (AgSnO)
Relay Type:	General Purpose
