HC1-HPL-AC100V-F

Part No :: HC1-HPL-AC100V-F

Manufacturer: Panasonic

Description: RELAY GEN PURPOSE SPDT 10A 100V

Catalog: Power Relays, Over 2 Amps

DataSheet: HC1-HPL-AC100V-F PDF

Availability: 0 pieces

Current price of HC1-HPL-AC100V-F is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

HC1-HPL-AC100V-F Specifications

Type	Description
Series:	HC
Package:	Bulk
Part Status:	Obsolete
Mounting Type:	Through Hole
Coil Voltage:	100VAC
Contact Form:	SPDT (1 Form C)
Contact Rating (Current):	10 A
Switching Voltage:	250VAC - Max
Coil Current:	13.2 mA
Coil Type:	Non Latching
Features:	Lighted Indicator
Termination Style:	PC Pin
Seal Rating:	-
Coil Insulation:	-
Must Operate Voltage:	80 VAC
Must Release Voltage:	30 VAC
Operate Time:	20 ms
Release Time:	20 ms
Operating Temperature:	-50°C ~ 60°C
Contact Material:	Silver Alloy, Cadmium Free
Relay Type:	General Purpose
