ORNV20022002TS

Image is for reference,
please contact us to get the real picture

Part No :: ORNV20022002TS

Manufacturer: Vishay

Description: RES NETWORK 5 RES 20K OHM 8SOIC

Catalog: Arrays/Networks Resistors

DataSheet: ORNV20022002TS PDF

Availability: 0 pieces

Unit Price: ~~$2.94000~~

Current price of ORNV20022002TS is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

ORNV20022002TS Specifications

Type	Description
Series:	ORNV
Package:	Tape & Reel (TR)
Part Status:	Active
Circuit Type:	Voltage Divider
Resistance (Ohms):	20k
Tolerance:	±0.1%
Number of Resistors:	5
Resistor Matching Ratio:	±0.05%
Resistor-Ratio-Drift:	±5ppm/°C
Number of Pins:	8
Power Per Element:	100mW
Temperature Coefficient:	±25ppm/°C
Operating Temperature:	-55°C ~ 125°C
Applications:	Voltage Divider (TCR Matched)
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	-
Size / Dimension:	0.194" L x 0.157" W (4.93mm x 3.99mm)
Height - Seated (Max):	0.068" (1.73mm)

Please confirm the specifications of the products when ordering.
